Compact vertical footprint
A 428 × 248 mm base keeps valuable floor space clear in indoor installations.
Indoor storage
Home storage
Floor-Standing Energy Battery
A vertical floor-standing battery for home and small commercial applications. Its narrow footprint and finished enclosure suit utility rooms, garages and dedicated energy cabinets.
Nominal energy10,240 Wh
Normal voltage51.2 V
Max I/O current200 A
Battery chemistryLiFePO4
Model reference: 51.2V200W · Custom configurations available on request.
System highlights
Practical power, thoughtfully configured.
10.24 kWh storage
A 51.2 V LiFePO4 battery with 200 A maximum charge and discharge current.
Complete integration options
CAN, RS485, Bluetooth and Wi-Fi communication are available for system control.
Technical data
Floor-standing specifications.
Standard model data is shown beside customization availability. Exact connector and communication options are confirmed before order.
| Parameter | Standard model | Customization |
|---|---|---|
| Model | 51.2V200W | yes |
| Battery Type | LiFePO4 | LiFePO4 / Ternary Lithium |
| Normal Voltage | 51.2V | / |
| Normal Energy | 10240Wh | / |
| Float charge voltage | 56.0V | / |
| Operating Voltage Range | 40.0~58.4V | / |
| Max.Charge Current | 200A | / |
| Max. Discharge | 200A | / |
| Storage temperature | 0℃~30℃ | 0℃~30℃ |
| Communication | CAN, RS485, Bluetooth, WIFI | CAN, RS485, Bluetooth, WIFI |
| Operating temperature | Charge: 0°C~+50°C Discharge:-20°C~+50°C | Charge: 0°C~+50°C Discharge:-20°C~+50°C |
| Humidity | 0~95%(no condensation) | 0~95%(no condensation) |
| Altitude rating | 4000m (Derating above 2000m) | 4000m (Derating above 2000m) |
| Net Weight | 88Kg | / |
| Gross Weight | 101Kg | / |
| Product dimensions (W × D × H) | 428*248*660mm | / |
| Package dimensions (W × D × H) | 508*428*800mm | / |
Please noteSpecifications are reproduced from the supplied ZHIFU product data. Connector type, communication protocol, packaging and final configuration are confirmed during quotation.
Made for the application
A versatile foundation for dependable power.
A 10.24 kWh vertical battery with a small footprint for clean, indoor energy storage. Communication, housing and interface options can be adapted to the final installation or product programme.
- Home energy storage
- Garage installation
- Solar backup
- Small commercial
- Capacity-matched cells and an integrated battery management system
- OEM / ODM options for housing, connector, protocol and branding
